LAB07 - FINISH MILLING - BUILD CUT and TOOL COMPENSATION
Автор: Gcode in AutoCAD
Загружено: 2025-03-23
Просмотров: 1651
Gcode in AutoCAD is a plugin that allows CNC programmers to create and verify Gcode files.
► ARROW displays the direction for selected objects.
► DELAR deletes all arrows displayed in the drawing.
► DELICO deletes all icons of working coordinate systems.
► DELE deletes all arrows, icons, and toolpaths.
► G54 defines the zero point of the G54 working coordinate system and makes an icon to mark.
► GCODE makes a file of Gcodes from selected objects.
► IDP displays the X, Y, and Z coordinates following a gcode working coordinate system such as G54 of a specified point in a drawing.
► INVERT changes the directions of selected objects.
► MTP opens and runs a gcode file.
► REVIEW redisplays each of the toolpaths that are displayed already.
Author: Thanh Che
Contact: thanhchenhat44@gmail.com
#facemilling #pocket #drilling #cncmachine #gcodeinautocad #programming
