How to Create Mesh Railings in Revit

Learn how to create custom mesh railings in Revit with a clear step-by-step process. From setting up a project and creating profiles to adding parametric elements, this tutorial ensures professional and precise railing designs.

If you would like to learn more about revit, head to archgyan.com - https://store.archgyan.com/

Timeline
00:00 Introduction
00:07 new project
00:16 Check Units
00:27 Create Simple Railing
01:04 Duplicate Railing
01:35 Horizontal Mesh Elements
02:33 Create Own Profile
03:00 Locking the Circle to the reference Planes
03:37 Parametric
04:18 Save Family
04:54 Category - Profile Usage
05:15 Load into Project and Close
05:27 Edit Profile List
06:13 Change Thickness - Parametric Circle Family
07:04 Adding Horizontal Mesh Elements
07:32 Adding Vertical Mesh Elements - Baluster Placement
08:38 Quick Hack - Replicate Profile
09:56 Horizontal Element for Support
10:34 Vertical Elements to Support Rail
13:18 Justify - Spread Pattern to Fit
14:05 Conclusion
