Nakamichi CR-7 (SN 0869x) : Serviced
Автор: CassetteDecksDepot
Загружено: 2025-07-24
Просмотров: 1526
Please visit my e-store : https://cassettedecksdepot.com/
Please check my repair projects on my Twitter : @DecksDepot
Please visit my stores on eBay and Reverb : @CassetteDecksDepot
Nakamichi CR-7 : Serviced. These operations performed:
transport disassembled, cleaned and relubed;
azimuth part cleaned and relubed;
belts replaced (Aftermarket);
idle tire replaced (Aftermarket);
pinch rollers replaced (Original);
reel motor replaced;
CAM motor replaced;
DD Motor PCB replaced;
PB head cable connection issue fixed;
"-12V" power board issue fixed;
"-12V" power DOLBY board issue fixed;
all pots and switches deoxited;
tape path alignment checked and corrected;
heads demagnetized;
playback speed (3kHz), wow & flutter checked;
playback levels (80Hz, 1kHz, 15kHz) checked and corrected;
azimuth (1kHz, 15kHz) checked and corrected;
record levels for all tape types supported checked and corrected, using embedded calibration module;
erasing for all tape types checked;;
all deck functions checked.
Regards,
Max, CDD
