Crane®FKX 9000 Triple Offset Butterfly Valves

Features and Benefits
1. Optimized Seat Angle:An innovative seat angle design and Stellite® hard-faced valve body seat deliver a longer seal life and improved abrasion resistance, even after extensive cycling. Designed to eliminate wedging or binding of the disc, and lower the operating torque, the Crane®FKX 9000 can REDUCE TOTAL COST OF OWNERSHIP BY UP TO 50%.*

2.Metal-to-Metal Sealing: The precision machined metal seat and seal ring deliver reliable and bidirectional shutoff in high temperature, highpressure and severe service applications among others. The right-angle conical seat design facilitates an almost FRICTION-LESS IN-LINE SEALING

3. Innovative Shaft Seal Design: permits superior FUGITIVE EMISSIONS CONTROL (ISO 15848, Class AH) under recurrent thermal cycling, and REDUCES POTENTIAL DOWN TIME.

4. Torque-Seating: Unlike position-seated ball, butterfly or plug valves, the torque-seated Crane® FKX 9000 self-adjusts to evenly distribute seal compression. A “floating” seal ring and wide seal ring supporting gasket yield a BETTER SEAL to eliminate binding and to enhance performance,
