RIELLO 40 G SERIES
The Riello 40 G series of one stage light oil burners, is a complete range of products developed to respond to any request for home heating. The Riello 40 G series is available in ten different models, with an output ranging from 12 to 240 kW, divided into four different structures. All the models use the same components designed by Riello for the Riello 40 G series. The high quality level guarantees safe working. In developing these burners, special attention was paid to reducing noise, to the ease of installation and adjustment, obtaining the smallest size possible to fit into any sort of boiler available on the market. All the models are approved by the EN 267 European Standard and conform to European Directives for EMC, Low Voltage, Machinery and Boiler Efficiency. All the Riello 40 G burners are fired before leaving the factory.

RIELLO R40G10 54,0 ÷ 120,0 kW
RIELLO R40G20 95,0 ÷ 213,0 kW
RIELLO R40 G20S 95,0 ÷ 240,0 kW

Part Support Ready Stock
RBL 530 SE control burner
RBL 530 Oil Pump
Foto Cell RBL 530 SE
Selenoid Valve RBL

STATE OF SUPPLY
Completely automatic monobloc light oil burners, one stage operation, made up of:
Fan with forward curve blades
Metallic cover lined with sound-proofing material
Air damper, completely closed in stand by, with adjustment
Single phase electric motor 230 V, 50 Hz
Combustion head fitted with:
stainless steel head cone, resistant to high temperatures
ignition electrodes
flame stability disk
Geared pump for fuel supply, fitted with:
filter
pressure regulator
attachments for fitting a pressure gauge and vacuum meter
internal by-pass for preparing for single-pipe installations
Fuel feed solenoid valve incorporated in the pump
Photocell for flame detection
Electronic flame control equipment
Light oil nozzle
IP X0D (IP 40) protection level
Fuel pre-heater (optional)
Reduced output ignition mechanism (optional).
Standard equipment:
Two flexible pipes for connection to the light oil supply line
Two nipples for connection to the pump
Flange, screws and nuts for fixing
Thermal gasket
7-pin plug (on request)
Maintenance assembly
Instruction handbook for installation, use and maintenance
Spare parts catalogue
