Looking to level up your LED screen setup for live events, concerts, or broadcast productions? This expert-led training dives deep into the essential differences between pixel mapping and scaling, equipping LED technicians, engineers, and content creators with the knowledge needed to build professional, distortion-free LED walls.

In this video, industry veteran Vittesh Patel—formerly with Screenworks NEP—shares insights from a decade of experience managing large-scale productions like EDC, WrestleMania, and Coachella. Whether you’re mapping multiple LED screen types or optimizing for aspect ratio integrity, this video provides a real-world, field-tested perspective.

🔍 What You’ll Learn in This Training:

What is Pixel Mapping?
Understand the concept of 1:1 pixel mapping, when and why it’s used, and how it ensures crystal-clear LED display output without content distortion.

Pixel Mapping vs Scaling
Explore the core differences between pixel mapping and various scaling techniques—free scaling, aspect scaling, and letterboxing. Learn how each affects image quality and presentation.

Common Pitfalls with Scaling
See how improper use of scaling can stretch faces, distort logos, and ruin the viewing experience. Learn best practices to avoid amateur mistakes.

Aspect Ratio Management
Learn how to preserve correct image proportions on non-standard LED screen dimensions using processors like Barco E2, NovaPro UHD Jr, and VX series.

Live Production Case Studies
Get a behind-the-scenes look at real setups from Coachella, WrestleMania, and Insomniac events. Analyze how pixel mapping templates and raster planning were used to create seamless visuals across multiple LED walls.

How to Create Pixel Mapping Templates
Step-by-step demonstration on building pixel map templates using tools like NovaLCT and Pixel Perfect LED software. Learn screen configuration, port assignment, panel mapping, and coordinate setup.

Using Mixed Pixel Pitch Panels
Discover how to combine various LED products (e.g., ROE CB8, Vanish 25, MC7) in one project using accurate pixel counts and processor mapping logic.

Best Practices for Live Changeovers
Learn why pixel mapping is critical for quick, zero-downtime VJ or artist changeovers during live events. Get tips on how to enable seamless transitions between content servers.

Software Tools: Pixel Perfect LED
Get introduced to the Pixel Perfect LED software developed by Red Dot Logics. See how it simplifies template creation for multi-screen environments with complex wiring layouts.

📌 Why Pixel Mapping Matters:

✔ Avoid content distortion (no stretched faces or broken logos)
✔ Enable multi-screen synchronization across diverse panel types
✔ Improve content creation workflow for playback servers and VJs
✔ Support realistic 3D stage visuals with perspective accuracy
✔ Deliver a polished, professional look for high-profile events

🎥 Featured Hardware & Software:

NovaStar VX4S / VX6S / VX1000

NovaPro UHD / UHD Jr

Barco E2 Switcher

Pixel Perfect LED (Red Dot Logics)

NovaLCT Software

Hippo & Disguise (D3) Media Servers


Pixel Mapping, Scaling, Aspect Ratio, Free Scaling, Letterboxing, NovaStar, VX Series, UHD Jr, LED Wall Setup, Live Event Video Engineering, LED Content Delivery, Mixed Pixel Pitch, Pixel Map Templates, NovaLCT, Pixel Perfect LED, Broadcast-Grade Mapping


Ready to optimize your LED screen setup and eliminate display distortion for good? Watch the full video and master the technical side of LED pixel mapping and scaling.
