แอมป์จิ๋ว XY-E100L 2.1
Автор: B DIY
Загружено: 2022-05-04
Просмотров: 5872
ฝากติดตามด้วยนะทุกคน
Support Sinilink-APP, modify the Bluetooth name, set the Bluetooth password, turn off/on the prompt tone
Achieve 360-degree stepless tuning and feel smooth, one-button start-stop, long-press switch machine operation is simple and convenient
Protection mechanism: electrostatic protection, overcurrent protection, short circuit protection, overheating protection
Product model: XY-E100L
Name: 2.1 channel Bluetooth audio power amplifier board module
Power supply: DC9-24V/3A above
Bluetooth version: 5.1
Audio channel: 2.1 channel
Audio input: Bluetooth + AUX
Audio output: left and right channels + subwoofer
Volume adjustment: high-end encoder knob adjustment feel smooth
Frequency range: 20HZ--30KHZ
Signal to noise ratio: 92dB
Output power: 50W x 2 (left and right channels) + 100W (subwoofer)
Satellite box (left and right channel) adapted speakers: 10W--50W/4 ohm--8 ohm
Subwoofer adapted speakers: 20W--100W/4 ohm--8 ohm
colour: black
Material: plastic
Size: about 70x73x20mm
Note:
The product needs to assemble the shell by itself, the assembly is very simple
The impedance of the adapted speaker is 4 ohms, and the power supply cannot exceed 12V
The impedance of the adapted speaker is 8 ohms, and the power supply cannot exceed 24V
Package Contents:
1 x Power amplifier board module
