MOD GUIDE: HIRricane Zeus (Full-Auto 90-Ball Capacity)

This is a full-length (50-minute) tutorial for my HIRricane mod, featuring my custom-designed 3D parts. The capacity of this version is 90 balls, with a quick load flip top. These are available on my website in four colors listed for sale in the link below. I STRONGLY recommend watching the whole video before starting your mod. It will save you time in the long run.

This video took 10 hours to shoot, and another whole day to edit. I hope it’s complete, but was a challenge to shoot due to the complexity of the mod. I’ll do my best to get annotations for table of contents.

NOTE: The current version does NOT need the Voltage boost circuit, as the new fan is much stronger. It also doesn't require shell cutting.

UPDATE:
Due to our supplier no longer carrying the appropriate fans, and due to the discontinuation of the Nerf Rival Zeus as a product available on shelves, we came to the unfortunate decision to discontinue selling kits and fully assembled HIR-ricanes.

However, we do sell our Proton Pack, which can be adapted to work with virtually any rival-compatible blaster -- including the Zeus:
https://outofdarts.com/collections/pr...

0:00 Opening
1:19 Parts & Supplies Required
3:49 Disassembling the Blaster
8:32 Converting the Blaster to Full-Auto
13:04 Dremel Demo
18:14 Installing the Flywheel Cutoff Switch
19:29 Modifying the Blower Fan
21:56 Cutting the Zeus Shell
26:39 Installing the Rev Switch
28:19 Wiring the Blaster
40:06 OPTIONAL - Cutting Charging Port Access
40:54 Wiring the Blower Fan
42:17 Adjusting the Fan Voltage
43:50 Reassembling the Blaster
45:55 Assembling the Tubing
48:15 Final Assembly
49:24 Firing Demo
49:47 Closing Remarks

Tube lengths: 5 tubes total (in order of ball flow)
10"
14 5/8"
15 1/2"
14 5/8"
10"

FULL COMPONENT LIST: (UPDATED WITH NEW ELBOW LINK on McMaster)

Blower: https://www.sparkfun.com/products/11270

Tubing: 1.09” polycarbonate tubing: This is available at mcmaster as 2044T47 http://www.mcmaster.com/#catalog/121/..., but Tap Plastics has the same thing, though they are selling it as florescent tubing guards. You also CAN use 1” PVC and 1” elbows available at any home depot/lowes, but you have to do some sanding to get the elbow to fit in the bottom.

Elbows: 1" ID elbows : http://www.mcmaster.com/#catalog/121/... (PART # 5035K33 on McMaster)

T- Junction 1" CPVC T (couldn't find on McMaster):
http://www.homedepot.com/p/NIBCO-1-in...

Top end cap:
http://www.homedepot.com/p/NIBCO-1-in...

Acrylic cement: http://www.amazon.com/SCIGRIP-10315-A...

16 Gauge hobby wire or hookup wire:
https://outofdarts.com/products/16-aw...

XT-60 connectors:
https://outofdarts.com/products/xt-60...

2x Microswitch (doesn’t have to be this one, just get a high amperage switch): http://www.mcmaster.com/#catalog/121/...

3 Cell Lipo (REQUIRED 3S to drive 12v blower):
https://outofdarts.com/products/zippy...

Other tools/supplies needed:
Hot Glue: Very handy for holding down wires in the frame.
Soldering iron/soldering station

Other tools/supplies needed:
Hot Glue: Very handy for holding down wires in the frame.
Dremel
Jig saw/Scroll saw (optional)
Soldering iron/soldering station
