NANO LEAF PART 2 | CLEAN & MODULAR DESIGN
Автор: Electronautic
Загружено: 2021-09-14
Просмотров: 18342
DIY NANO LEAF WITH NODE MCU PART-2 |CLEAN & MODULAR DESIGN
In this part, I will show how to build Nanoleaf from broken mobile displays with a better and clean design than part-1.
STL file and connections diagram- -https://www.thingiverse.com/thing:494...
\\\\\\\\\\\\\\\\module\\\\\\\\\\\\\
0:00 starting
00:29 moduler overview and intro
00:44 3d printing
00:53 assembling
01:55 connection and wiring diagram
02:07 led & diffuser installation
08:30 software installation
10:40 esp connection diagram
11:06 ending
\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\
CONTROLLER USED- NODE MCU v3
LED STRIP- WS2812b addresable led strip(5v)
HERE,ARDUINO UNO, NANO WILL ALSO WORK (NON-WIFI CONTROLL) FOR MORE INFORMATION VISIT THE GITHUB PAGE
https://github.com/kitesurfer1404/WS2...
Comment below for any query
