Building A Triple Axle RC Boat Trailer From Scratch (CHEAPER THAN BUYING)

This took me longer than I’d like to admit lol. Hopefully this helps you out with your build! Launch and recovery video coming soon! Build Sheet below.

Shoutout to ‪@soflorclife6970‬

Materials
Home Depot
Angle Aluminum - 3/4 in x 96 in 1/20 in Thickness
Flat Bar Aluminum - 1/2 in x 36 in 1/16 in Thickness
Aluminum Sheet/Sheet Metal - 6 in x 18 in 0.025 in Thickness
Threaded Rod - #8-32 x 36 in
#8 Machine Hex Nuts
#8 Lock Nuts
Flat Washers (Optional)

eBay
Wheels - Diameter 68/52mm (With/Without Tires) Width 26mm Mount 12mm Hex https://www.ebay.com/itm/373604622251... (any 1/10 scale rally car/offroad car wheels will most likely be fine)
Foam Tape - 15mm x 5mm 3mm Thickness https://www.ebay.com/itm/404549462387
RC4WD Scale Aluminum Diamond Plate https://store.rc4wd.com/Scale-Diamond...

Harbor Freight
Rivets - used mostly 3/32 in and 1/8 in, some 5/32
Epoxy (any is fine, I used Platic Weld)

Tools (Some are optional - all can be found at Harbor Freight)
Drill
Drill bits (3/32 in, 1/8 in, 5/32 in or whatever size your rivets are)
Hand Riveter
7 in Diagonal Cutters
Rotary tool
8 in Flat File
Measuring Tape
Mini Spring Clamp Set
Clamp

Hopefully I'm not missing anything. If you have any questions, ask away in the comment section! Thanks for watching, if you enjoyed the video don’t forget to subscribe to Jonny’s Hobbies!
