Single Supply 0-12 Bass Treble Mid Circuit Diagram - JRC4558 Opamp -High Bass Punch With High Gain
Автор: New Generation 123
Загружено: 2023-03-07
Просмотров: 6332
SINGLE SUPPLY 0-12 BASS TREBLE CIRCUIT DIAGRAM
COMPONENT LIST:
OpAmp ic = JRC4558 x 2
Resistors,
20k x2
100k x 2
100ohm x 2
1k x1
10k x 5
3.3k x 2
1.5k x 2
E.L Capacitor
16v 1uf x 2
16v 100uf x 1
16v 10uf x 1
16v 4.7uf x 1
NP Capacitor
33p x 1
47n x 2
22n x 1
4.7 x 2
Friends aaj ki video main bass treble ka circuit diagram dia gaya hai is circuit main laudness aur bass punch acha hai aur ye single supply se chalta hai.
agar video resolution thik nahi lage to apne youtube settings se video resolution increase karen.
video k akhir mai diagramki comlete pic di gai hai ap screen shot le saktay han.
video achi lage to like karna channel ko subscribe karna
#BassTrebleCircuit #singlesuply
