Can-Am Defender Automatic Reverse Light Install

A wide array of Can-Am and Polaris lighting accessories are also available at https://samsbackuplights.com/

This video is a step-by-step walkthrough on how to install our automatic reverse light kit on your Can-Am Defender.

Our automatic reverse light kits are easy to install and operate; they require no extra buttons or switches. The lights will automatically come on when the vehicle is shifted into reverse. We have also programmed in an override function so that the lights may be used when not in reverse. To use this function, shift to neutral and press and hold the brakes until lights come on. Repeat the process to shut them off.

Email: [email protected]
Website: https://samsbackuplights.com/

0:00 Introduction
0:04 Remove cover
0:12 Plug in diagnostic connector
0:19 Plug in bullet connector
0:28 Reinstall cover
0:37 Remove dash
0:50 Plug jumper into white and blue wires
1:11 Reinstall dash
1:45 Remove headliner bolts (Torx T15)
1:55 Remove speaker (Allen 3mm)
2:37 Remove dome light (5.5mm or 7/32 )
2:44 Pull headliner down and unplug dome light
3:35 Mount light (12mm)
3:49 Drill 5/16 hole and insert grommet
3:59 Feed wires into cab
4:07 Install light bracket (Torx T40)
4:58 Assemble light connector
5:47 Remove passenger pillar cover (Torx T25)
6:17 Feed wires down inside of passenger pillar
6:36 Pull wires through on bottom side
7:02 Run wires to back of cab behind battery
7:15 Remove battery cover and floor panel
7:54 Plug in relay and attach ring terminals to battery
8:38 Plug in lights
