Three-Phase Full Bridge Controlled Rectifier | Variable DC Output in MATLAB Simulink
Автор: SimuScope
Загружено: 2025-09-25
Просмотров: 103
📌You can get the Simulink file on this concept from the link giving in my Bio.
In this video, we demonstrate a Three-Phase Full Bridge Controlled Rectifier in Simulink and show how adjusting the firing angle (α) changes the average DC output voltage.
🔹 What you’ll learn:
Basics of a 3-phase controlled rectifier
How the firing angle affects DC output
Simulation setup in Simulink with Universal Bridge and PLL
Voltage and current measurement across a resistive load
Practical applications in power electronics and motor drives
This simulation is ideal for students, educators, and engineers who want to understand how controlled rectifiers are modeled and analyzed in MATLAB/Simulink.
📌 Subscribe to SimuScope for more MATLAB/Simulink tutorials, power electronics projects, and ready-to-use simulation files.
👉 Don’t forget to like, share, and comment with your thoughts!
