ARB Bull Bar (Bumper) Install - Toyota Landcruiser 100 Series / Lexus LX470

How to install an ARB Bull Bar on a Toyota Landcruiser 100 Series (IFS model, UZJ100 or HDJ100) or Lexus LX470, year models 1998-2007.

This video covers the full bull bar install including wiring of the new indicators and parker lights.
How to remove the factory Toyota bull bar (alloy) from the 100 Series Landcruiser is also included.

Jump to Section:
0:00 Introduction
00:15 Removing the Toyota factory alloy bull bar
02:12 Installing new bull bar brackets
07:47 Installing 10mm and 6mm cage nuts
08:34 Installing rubber bumpers onto the bull bar
09:51 Lifting on, adjusting, and bolting the new bull bar
10:57 Installing pinning bolts
12:33 Installing new front bash plate
14:38 Wiring of new indicators and parker lights.
19:49 Installing new light surround and lights
22:02 Installing license plate and Conclusion
22:42 Bloopers

Products Installed:
ARB Bull bar – Product no. 3413190 (winch) or 3213190 (non-winch)
Comes with ARB Fitting Kits – 6172338 and 6172342
Comes with ARB Light Surround Kit – 3163015

Tools and Parts:
Metric socket set and spanners – 10, 12, 16, 17, 18, 19 and 22mm required
Socket wrench and extension to suit above sockets
Breaker bar or impact wrench (recommended)
Phillips head and flat head screwdrivers
Hacksaw or angle grinder with cutting disc (recommended)
Flat and round files
Ruler and pencil
Black paint and paint brush for touch-ups
Claw hammer and centre-punch
Masking tape
Drill
Metric drill bits for steel, up to and including 10mm and 13mm
Measuring tape
Narva 56473BL 3-way waterproof connector with terminals and seals
Scissors or blade
Wire cutters
Wire strippers
Crimping tool

Recommended Personal Protective Equipment (PPE):
Safety glasses
Ear plugs or earmuffs
Gloves
Secondary eye protection (if using grinder)

Disclaimer: At 2nd Gear Low, we love working on cars, but we are not trained mechanics. We like completing maintenance and modifications to all sorts of cars and filming it for your entertainment, but we can’t promise that you won’t harm yourself, someone else, your car or your warranty by trying this. Talk to a qualified mechanic if you are ever unsure about any part of a job that you choose to try yourself.
