Part 1 JETWING EDF (LW-PLA)(Rudder) by PLANEPRINT 3D printed RC plane

Free tuning parts for wing servos available on the Planeprint page.

We are absolutely thrilled with the Jetwing.
From the concept behind it and from the implementation and the flight behavior. Hand launch, ground launch go without problems, the thing is fast, glides very well and makes us only fun, printed quickly, always fits in the car.
Congratulations to Planeprint on this jet!

JetWing:
Wingspan: 1270 mm
Flight weight: 1490 grams
Wingload: from 48g/dm2
4 channel
Motorization: EDF 70 mm, 4S


The components are the same for both:

Wing servos: CS238MG
Rudder servo: DS939 MG

EDF: Technical data:
Hacker Stream-Fan 70mm kv3750 (Wemotec Evo)
Motor: E40-S 1Y
Impeller: 9-blade glass fiber reinforced
Number of cells: 4S LiPo
15° motor timing
Thrust in grams: 2000g

Speed controller: YGE 90 LV

Battery: SLS 4000mAh

Flight weight:
1. 1465g
2. 1481g (Wheels)

All settings taken from the manual and fit very well.

Printers we have used:

4x Artillery Genius
2x Anycubic Vyper
1x Snapmaker 350T
1x Artillery Sidewinder X1
1x Anycubic Mega X

Flilament:
Sunlu PLA+
Polylight LW
Esun LW

Links:
Planeprint JetWing side:

https://www.planeprint.com/jetwing

Manual:
https://www.planeprint.com/_files/ugd...
