Moriseiki MS-1250 Engine Lathe

This machine has been sold. Please call for similar models.

MACHINERY CONSULTANTS INC
Bill Jr., Technical Sales Manager, Director of Operations
1390 West 200 South
Salt Lake City, Utah 84104
Office Phone 801-531-9500
Office Fax 801-531-9555
E Mail for mci@machineryconsultants.com
Our website: www.machineryconsultants.com

Hello from Bill Wilson jr.
We are pleased to offer, subject to prior sale and our conditions of sale, the following for your consideration:
Pre-Owned Moriseiki 17” x 49” Engine Lathe
Model: MS1250 Serial No: 6847

General specifications are approximate and are subject to verification.

Swing over bed: 17 1/8”
Swing over slide: 9 3/4"
Max center distance: 49”
Spindle nose: A 1 6
Spindle bore: 2”
Spindle speeds: 12 Changes from 32 to 1800 RPM
Tailstock Taper: #4 MT
Width of bed: 14”
Threads: 35 Changes from 4 to 80 TPI
Threads in Metric: 21 Changes from 0.25 to 7 MM
Feeds: 40 Changes from .0010 to .0250 IPR
Feeds in Metric: 40 Changes from .0250 to 3.5 MM
Main motor: 220/440 Volt
Electricals: 7.5 HP
Approx. Weight: 5,000 Lbs.
Approx. Dimensions: 98” L x 33” W x 50”H

Complete with:
• 10” 3 Jaw Chuck
• 12” 4 Jaw Chuck
• Hardened Ways
• Tool Block
1 Holder
• Coolant Pump, Spigot & Nozzle, all updated OEM Items
• Chip Pan, Built into Casting Frame Type

Condition: Runs Very Well. Great Toolroom Lathe.

Inventory No: 6844
