Installing the Rapid Change Easy ATC on Onefinity Elite Masso

This is a revised video that adds more details, clarity and context to the original video. Ok, so this video is loooong!! This covers the installation of the Easy ATC onto the Onefinity Elite Machines complete from start to finish and includes how to install wiring in the Masso controller; determining location for your ATC and creating toolpaths to drill locating holes (Carveco and Vectric files and svg files included) and installing the ATC onto your spoilboard; all the necessary settings in the Masso setup screens; capturing than entering the appropriate data into the Rapid Change WebUI; and creating the subroutines for effective operations along with some test cycling and carving. Always read the Onefinity and Rapid Change manuals for more detailed instructions and be sure to use the appropriate Post Processor for use with the ATC.

**NOTE: USE THE MACHINE COORDINATES FOR TOOL POCKET AND TOOLSETTER LOCATION AND FIND Z- Not the coordinates on the DRO **

Carveco_Vectric_SVG files:
https://1drv.ms/f/c/cbf76025afc5bcd9/...

Chapters:
1:41 Components
2:42 ATC Wiring in Masso
9:13 Spindle CCW Wiring
10:37 Locating ATC Riser
11:37 Vectric layout
17:22 Carveco layout
22:32 Attaching Riser
23:31 Attaching ATC
24:01 Attaching Toolsetter
24:40 F1 Settings Toolchanger
27:11. F1 Settings Aux Inputs
29:27 F1 Settings Auto Tool Zero
30:32 F4 Settings Tools
33:30 Web UI
36:18 Web UI Find Z
38:30 Pocket Fine Tuning with locating disc
41:55 Find Z on machine
43:10 Enter Data & create subroutines
51:22 Adjusting cups for tool length
53:10 Start up with subroutines
54:19 Tool Change Test
50:45 F1 Settings Adjusting for Efficiency
