PLC OMRON CONNECT NODE RED

PLC OMRON NX1P2-9024DT NODE RED (COMMUNICATION FINDS OMRON)
CONFIG PLC OMRON NX1P2-9024DT
CREATE PROJECT SOFTWARE SYSMAC STUDIO
SET IP 192.168.250.1.
CONFIG FINDS
ADD MODUL ETHERCAT
CREATE VARIABLE CONTROL: ADDRESS CONFIG I/O HARDWARE.

CONFIG NODE RED
CREATE PROJECT
ADD DEVICE PLC OMRON ETHERNET NX (NX1P2)- SELECT IP:192.168.250.__1
IMPORT TAB VARIBLE PLC OMRON FROM FILE TAG.TXT
CREATE ICON BUTTON ON/OFF - LAMP_00 : CONTROL OUTPUT_0(D10).
CREATE CELL INPUT TEXT VARIBLE REGISTE CONTROL OUTPUT MODUL OD5121(16 OUT) - ETHERCAT

CONFIG SET IP PC: 192.168.250.XXX.(differen ip PLC :192.168.250.__1)

-------- THANK YOU WATCHING ---------
