017 - workshop - Dog Hole Jig for MFT/Parf System Module Holes

Building a set of jig plates to precisely align MFT/Parf holes on modules for the build of a workshop island.

With proper hole starts and using the UJK drilling system, extremely accurate hole patterns can be set up in multiple modules so they can be joined for a coherent and precise large work surface. The emphasis is on accuracy and being able to manage large sheet goods solo in the shop.
