Testing a Siemens valve actuator with a 0 to 10VDC control signal and feedback
Автор: KB3PML
Загружено: 2016-02-02
Просмотров: 32186
This video demonstrates the operation of a Siemens actuator controlled by a 0-10VDC signal. An actuator controls the position of a water valve or an air damper in an HVAC system. This actuator provides feedback of its real-time position with another 0-10VDC signal that we can read with a voltmeter or a BAS analog input. This feedback signal provides proof to the controller that the actuator is functioning properly, obeying commands, and the signal can be used as a position readout on the user interface.
I wish to express my appreciation to the Energy Management Department at the Owens Campus of Delaware Technical Community College in Georgetown, Delaware for their support and for the use of their equipment and space.
