MELLOTT - 6 ft. Bandsaw Tilted 17 Degree - Soapstone Sawmill, Peach Bottom, PA

MELLOTT MODEL 642 TILTED 17° BANDSAW, HYDRAULIC (optional electric unit with 24 volt, DC)
BANDSAW BLADES: 12” x 42’
BASE AND COLUMNS: HEAVY DUTY BASE AND COLUMNS
UPPER WHEEL: 72” DIAMETER CAST DUCTILE IRON WITH LINK BELT DOUBLE ROW SPHERICAL BEARINGS
LOWER WHEEL: 72” DIAMETER CAST DUCTILE IRON WITH TIMKEN AP SERIES (RAILROAD CAR) BEARINGS
UPPER WHEEL GUIDES: 8” DIAMETER SBN (SALT BATH NITRITED) TREATED GUIDES
UPPER WHEEL LIFT: (2) 10 TON WORM SCREW JACKS, HYDRAULICALLY DRIVEN
UPPER WHEEL TILT: (1) 10 TON WORM SCREW JACK WITH 3/4 HP ELECTRIC DRIVE
STRAIN: ECCENTRIC TYPE AIR TENSION WITH SAFETY SPRING
SAW GUIDES: CARTRIDGE TYPE UPPER AND LOWER PRESSURE GUIDES
UPPER GUIDE TRAVELS ON HARDENED ROUND WAYS
MANUAL UPPER GUIDE CONTROL WITH HYDRAULIC CYLINDER
WHEEL GUARD: PIVOTING UPPER WHEEL GUARD, HYDRAULIC OPERATED
INCLUDES AIR FILTERING AND PRESSURE CONTROL SYSTEM FOR STRAIN
INCLUDES ALL HYDRAULIC VALVES, FLOW CONTROLS, ETC FOR SAW FUNCTIONS
INCLUDES PUSHBUTTONS, SWITCHES, ETC. FOR LIFT, TILT AND SHIELD
INCLUDES GUIDE BLOCK DRESSING MACHINE WITH AN EXTRA PAIR OF GUIDE BLOCKS AND GUIDE BLOCK HOLDERS
DOES NOT INCLUDE MOTOR STARTERS
ASSEMBLED WEIGHT: 24,500 LB.
MELLOTT MODEL 90ES, 30” WIDE OFFBEARER (17 DEGREE TILTED SAW)
SPECIFICATIONS:
FRAME: HEAVY DUTY FRAME, CONSTRUCTED FROM 3/4” PLATE, WEIGHT OF FRAME AND SHEAR RAIL IS 1,100 LB.
PULLEYS: 8” DIAMETER HEAVY WALL CROWNED FACE WITH BROWNING SPLIT TAPER TYPE BUSHINGS TO 1-15/16” DIAMETER SHAFTS
SHEAR RAIL: 3/4” MACHINED PLATE WITH BRASS INSERT
BEARINGS:
DRIVE: REXNORD DOUBLE ROW SPHERICAL FLANGE BEARINGS
TAKE UP: WIDE SLOT TYPE BEARINGS WITH BOLT ON TAKE UP FRAME
DRIVE: EATON 2,000 SERIES HYDRAULIC MOTOR
BELT: 30” WIDE PVC CBS 350
INCLUDES SOLENOID OPERATED CONTROL VALVE AND FLOW CONTROL
ASSEMBLED WEIGHT: 26,100 LB

For more information, please visit our website www.mellottmfg.com or call 717-369-3125.
