Enforcer™ 75’ Aluminum Ladder
Автор: PierceMfg
Загружено: 2018-05-17
Просмотров: 6657
Take a walk around our stock 75’ #Enforcer Aluminum #QuintLadder that was on display at FDIC. This 1,500 gpm aerial has a 750 lb tip load, a trash line in the front bumper, provisions for foam and four discharges, spacious compartments, and a 16’ stabilizer spread. The rear features ladder access to the turntable in addition to pike pole and 115’ ground ladder storage.
CHASSIS
Chassis: 70” Enforcer
Seating Capacity: 6
Overall Height: 11' 6”
Overall Length: 38’ 1.5”
GVW Rating: 53,500 lb
Front/rear axle: Dana D-2000F, 20,000 lb - Meritor RS30-185, 33,500 lb
Engine: Cummins L9, 450 hp, 1250 torque
BODY
Pump: Waterous, 2000 gpm
Tank: 500 gallon
Pump Panel: Pierce Control Zone 52” pump house
Foam System: Provisions for future system
Foam Cell: 25 gallon
Doors: Gortite roll up
AERIAL DEVICE
Device: 75’ aluminum ladder, 3-section aluminum aerial
Tip load: 750 lb dry, 500 lb wet
Equipment: 100 lb allowance
Flow Rate: 1500 gpm
Stabilizers: 1 set of H-style, 16” spread
