Designing a simple 5-step sequencer from scratch
Автор: Moritz Klein
Загружено: 2022-03-14
Просмотров: 125566
Support the channel...
... through Patreon: / moritzklein
... by buying my DIY kits: https://www.ericasynths.lv/shop/diy-k...
Working simulation on falstad: https://tinyurl.com/yestfcv9
Voltage dividers in-depth: • Designing a classic transistor-VCA from sc...
In this episode, we're building a really simple, 4017-based 5-step DIY sequencer. It's a great companion to my SHAPES VCO. if you want to build along, here's the bill of materials:
1x CD4017 decade counter
1x TL074 quad op amp
5x BC548 NPN transistor
5x LED
5x 100k linear mono potentiometer
1x 5k trimmer potentiometer
13x 1N4148 diode
10x 100k resistor
1x 68k resistor
1x 51k resistor
7x 1k resistor
3x jack socket
Chapters
00:00 Intro & what is a sequencer?
03:52 The 4017 decade counter
12:36 The CV output
19:43 Safe status LEDs
21:45 The gate output
28:15 Final design & outro
