Raspberry Pi CM5 IO board and IO case overview and assembly
Автор: blackdevice
Загружено: 2025-12-15
Просмотров: 1011
This video is a clear walkthrough of the official @raspberrypi Compute Module 5 IO board and the matching IO case. In this video we'll show you every connector and feature that makes this platfom ideal for development and embedded projects.
Guided tour of the IO board layout: RTC battery, HDMI 2.0 ports, Ethernet (PoE via J9), USB 3.0, USB-C, microSD slot.
M.2 key M socket overview for NVMe storage and how it fits into the board.
Fan and cooling strategy.
MIPI DSI/CSI connectors, power button location, and standard 40-pin GPIO for HATs.
Quick assembly: mounting the CM5, securing the board and closing the official metal IO case.
Official product pages for full specs and downloads:
🔗 CM5 IO board: https://www.raspberrypi.com/products/...
🔗 CM5 IO board data sheet:
https://pip-assets.raspberrypi.com/ca...
🔗 IO case for CM5: https://www.raspberrypi.com/products/...
Got a project idea for this setup? Drop it in the comments — we’ll try the best suggestions in future builds.
If you found this useful, please like the video and subscribe 🔔 for more Raspberry Pi hardware deep dives and DIY tutorials.
