2003 - 2008 Toyota Matrix Corolla Valve Cover Gasket Replacement, Full bolt by bolt DIY (1ZZ-FE)

This video shows how to remove and replace the valve cover and gasket on a Toyota 1ZZ-FE engine, found in the Matrix, Camry, and other models. Check the Pinned Comment or below for Timestamps, Part numbers, Torque Values, and links:

00:18 Diagnostics
02:44 A make a bolt template
04:09 Disconnect the electrical connectors for the ignitors
05:20 Remove two fasteners for the electrical harness (10mm)
05:50 Remove four bolts for the ignitors (10mm)
06:12 Remove the ignitors
07:07 Disconnect the breather hose
07:35 Disconnect the hose to the PCV valve
08:16 Locations of the Valve Cover fasteners (ten 10mm, one 12mm)
09:38 Slip the harness off of the three brackets for easier access
10:45 Remove the Valve Cover fasteners
15:49 Tie up the electrical harness for easier access
16:20 Remove the Valve Cover
18:27 Clean the gasket mating surface

18:44 Note about Timing Chain Tensioner Repair and Video to consider while doing this job

20:00 Remove the old gasket (Toyota 11213-0D040, or Fel-Pro VS 50542 R)
20:41 Clean the Valve Cover gasket channels
21:09 Install the new gasket to the Valve Cover

22:49 Remove the old FIPG/RTV from the head

23:54 Apply new FIPG/gasket-maker/RTV onto two places on the head (I use Permatex Ultra
Black RTV)
25:39 Install the Valve Cover
26:04 Install the fasteners for the Valve Cover (Perimeter bolts/nuts: 96 inch-lbs;
Center bolts: 80 inch-lbs)
29:38 Reconnect the electrical harness to the brackets
30:25 Re-install the ignitors and bolts (80 inch-lbs)
30:48 Re-install the electrical harness fasteners (80 inch-lbs)
31:14 Reconnect the electrical for the ignitors
31:41 Reconnect the two breather hoses
32:49 Allow the RTV to cure (overnight is always good)

Here is the video mentioned at 01:59:
   • 2003 - 2008 Toyota Matrix Corolla 1ZZ-FE T...

Here is is the video mentioned at 24:41:
   • 1ZZ-FE Warped Cylinder Head Success Story ...

I hope this video was helpful for you. Thank you for watching, and good luck with your repair!
