I hope you enjoy the latest in the homestead series! Cutting instructions can be found below:
Cutting Instructions for Kitchen Table and Chairs
For pieces marked with an asterisk (*), it is recommended that you wait and cut when you get to that step in the process.
Table
Cut from 2.5mm (3/32”) thick wood sheet
Letter Quantity Metric Imperial Title
A 1 75mm x 51mm 3” x 2” Table top
Cut from 1.5mm (1/16”) thick wood sheet
B 2 61mm x 10mm 2 ⅜” x ⅜” Table sides
C 2 36.5mm x 10mm 1 ⅜” x ⅜” Table sides
Cut from Square Dowel 5mm (3/16”) thick
D 4 13mm ½” Legs
Cut from Round Dowel 5mm (3/16”)
E 4 7mm ¼” Legs
F 4 35mm 1 13/32” Legs
G 4 10mm ⅜” Legs
Chair - The following pieces are per/chair.
Cut from 2.5mm (3/32”) thick wood sheet
H 1 28x33x35x33mm 1 ⅛ x 1 5/16 x 1 ⅜ x 1 5/16” Seat
Cut from Square dowel 3.5mm (1/8”) thick
I 4 37mm 1 7/16” Legs
J 2 33mm 1 5/16” Back posts
Craft Matchsticks 2mm (3/32”) thick
K 4 22mm ⅞” Front/back supports
L 4 23mm 29/32” Side supports
Cut from 1.5mm (1/16”) thick wood sheet
N 1 26x22x32x22mm 1 x ⅞ x 1 ¼ x ⅞” Back support 1
O 1 23mm x 5mm 29/32” x ⅜” Back support 2
P 2 13mm x 6mm ½” x ¼” Decorative top
