SeaDoo Switch Tank Adapter
Автор: Let's Roll! DIY Auto
Загружено: 2023-05-27
Просмотров: 5498
If you like these videos, please subscribe. This video shows how to install a Yacht Devices Tank Adapter in a Sea Doo Switch for displaying the remaining fuel in gallons on your Garmin. It is an addition to the Yacht Devices Engine Gateway. If this has helped, please like and subscribe.
Note: PK/BK should be connected the positive (red) wire on the Yacht Devices Tank Adapter and the PK should be connected to the ground (black) wire on the device. The video shows the reverse. Due to the nature of the device and SeaDoo gauge, it didn't seem to make much difference, but to do it right, make this adjustment.
Yacht Devices Tank Adapter: https://amzn.to/45Bg9SI
Quick Splice Kit: https://amzn.to/45wFg99
Garmin NMEA 2000 T Connector: https://amzn.to/43wWGAu
Micro SD Card: https://amzn.to/3WAh69J
Volt/Ohm Meter (cheap one): https://amzn.to/43aCNiS
Volt/Ohm Meter (ultimate): https://amzn.to/3WFneNG
Here is a follow-up: I was looking into calibration and asked Yacht Devices. Here is their answer: "BRP fuel level sensor is not just a resistive sensor, but a stepped one (you can check it on your sensor). So, you have only 9 fixed values for this sensor, and this can not be fixed by calibration. Сalibration can only refine these fixed values." So you will not see the gallon by gallon drop on your Garmin. You will see a step drop similar to the bar gauge on the multifunction display (only reading gallons).
The following should be placed on a freshly formatted Micro SD Card with the file name: YTDA.txt
------Copy and paste all below this line---------------
Current configuration of Yacht Devices Tank Adapter
Firmware version: 1.05 09/10/2019
NMEA 2000 SETTINGS
TANK=0
FLUID=DIESEL
DAMPING=3
CONNECTION AND SENSOR TYPE
CONNECTION=VOLTAGE
RESISTIVE SENSOR SETTINGS (EUROPE: 10..180, USA: 240..33, JAPAN: 0..310)
OHMS_EMPTY=240.0
OHMS_FULL=33.0
VOLTAGE SENSOR SETTINGS
VOLTS_EMPTY=1.0
VOLTS_FULL=0.0
REFERENCE=12.0
ANALOG GAUGE SETTINGS
OHMS_COIL_1=200.0
OHMS_COIL_2=200.0
OHMS_WIRES=0.0
TANK SIZE AND SHAPE
CAPACITY=UNKNOWN
CALIBRATION=OFF
DIGITAL SWITCHING RULES
SW1_ON=NEVER
SW1_OFF=NEVER
SW2_ON=NEVER
SW2_OFF=NEVER
SW3_ON=NEVER
SW3_OFF=NEVER
SW4_ON=NEVER
SW4_OFF=NEVER
SENSOR DATA RECORDING
LOG=OFF
INTERVAL=10
SWITCH THE ADAPTER TO PRESSURE SENSOR
PRESSURE_SENSOR_PA=OFF
End of file
