Yamaha MT- 03 / FZ-03 Zero S / SR / DS / DSR | Bi-Xenon Headlight Projector Upgrade DIY installation

𝗬𝗼𝘂 𝗰𝗮𝗻 𝗯𝘂𝘆 𝘁𝗵𝗶𝘀 𝗴𝗿𝗲𝗮𝘁 𝘂𝗽𝗴𝗿𝗮𝗱𝗲 𝗸𝗶𝘁 𝗵𝗲𝗿𝗲:
https://retrofitlab.com/products/yama...

𝗜𝗻𝘀𝘁𝗿𝘂𝗰𝘁𝗶𝗼𝗻𝘀:
0:11 Unscrew the bolts on the back of the housing and get off the frame. After that's done, take off all parts on the front and put it in the carton box (or oven for about 5 minutes on 200 degrees "pre-heat only" ) for about 17 minutes, turn the headlight upside down by half time.
0:39 Separate the glass gently by using a flat screwdriver. It's sealed by permaseal, so it could take more time as just pull it open, you have to remove the sealant inside completely before closing the headlight later.
1:02 The inlay is bold with 3 screws under the sealant, don't forget them otherwise you'll break the inlay
-Try to touch all chrome parts and lenses with gloves only!!-
1:27 Mount all hardware like we show in the video, you have to reuse some parts from the old reflector.
2:47 Now you're ready to screw the projector in the bracket, and attach the Mini Gatlin Gun shroud with the same screws directly on the projector. You need the brass screws instead of the black m4 bolts.
3:48 Replace the complete bracket with projector back in the housing and mount the inlay as well.
4:25 Add some new butyl rubber sealant for a waterproof connection and press the glass back on the housing.
5:02 Put it back in the carton box for 16 minutes again.
5:16 Mount the bulbs holder on the back, drill a 22mm hole in the rubber cap and put it all together.
- you have to unplug the solenoid wires and put them trough the rubber cap as well-
7:05 Screw back all screws you've unscrew before, and mount the black frame again.
7:23 You do have a pretty good looking projector headlight for you Yamaha MT03 now!

𝗔𝗱𝘃𝗮𝗻𝘁𝗮𝗴𝗲𝘀 𝗼𝗳 𝗮 𝗕𝗶-𝘅𝗲𝗻𝗼𝗻 𝗽𝗿𝗼𝗷𝗲𝗰𝘁𝗼𝗿 𝗿𝗲𝘁𝗿𝗼𝗳𝗶𝘁 𝗸𝗶𝘁:
• Much better light output
• Double high beam (xenon + halogen)
• No glare
• Lower energy consumption (35 watt instead of 55 watt)
• Luxury OEM look

𝗧𝗵𝗶𝘀 𝗸𝗶𝘁 𝘄𝗶𝗹𝗹 𝗳𝗶𝘁 𝗼𝗻:
• Yamaha MT-03 (2006 - 2013)
• Zero DS
• Zero S

𝗖𝗵𝗲𝗰𝗸 𝗼𝘂𝘁 𝗼𝘂𝗿 𝗻𝗲𝘄 𝗙𝗮𝗰𝗲𝗯𝗼𝗼𝗸 𝗴𝗿𝗼𝘂𝗽:
  / europeanheadlightcommunity

𝗙𝗶𝗻𝗱 𝘂𝘀 𝗼𝗻:
Facebook:   / retrofitlab
Messenger: https://www.m.me/Retrofitlab/
Instagram:   / retrofitlab.com_official
Our website: https://www.retrofitlab.com/

𝗢𝘂𝗿 𝗦𝘁𝗼𝗿𝘆:
Retrofitting refers to the addition of new technology or features to older systems. These days there are a lot of people who put a simple plug & play xenon kit in their halogen headlight housing in an attempt to improve night vision and looks of their vehicle. In fact they don’t realize that their headlight beams are often worse than before. Night vision achieves relatively little improvement on night vision because of a poor beam pattern, which increases the blinding of other road users. This is because their headlight housings are designed for halogen and not xenon.

A true Bi-Xenon projector update is now possible for your car. Such an upgrade will significantly improve your light output from 700-2100 lumens to 2800 and 3500 lumens, without blinding other traffic with glare from your headlight. Upgrade your headlight OEM style!

The latest high power Led bulbs will upgrade both the exterior and interior lighting system of your car. Led lighting is becoming more and more popular in the automotive market for obvious reasons. They have longer lifetime, use less energy and improve safety with their fast response time.

Do you have any questions? Do not hesitate to contact us, we are happy to help you out!

Good luck with your retrofit!

These products are not ECE-approved and must not be used on public roads in any exterior application. Use on public roads will invalidate both the operating license and insurance coverage.
