Look inside JBL LSR308 Studio monitors - Disassembly

Teardown - Look inside JBL LSR308 8 inch powered professional studio monitors. How to disassembly & assembly this JBL LSR 308 and What is inside a speaker? They cost less then they sound. I hope someday compare the JBL LSR308 vs JBL 308P MkII 8-inch 2-way monitor. At this moment the JBL LSR308 are discontinued and they replaced JBL 308P MkII newer model. They seem very similar jbl lsr305 and JBL 305p speakers. I hope closest future we teardown jbl lsr305 or JBL 305p. Some alternative studio monitors are yamaha hs8, krk rokit 8 or adam t7v. Check also jbl lsr308 comparison sound test. Definitely these are one of best budget studio monitors for the $400-500 price point.

JBL LSR308 Studio monitor specifications:
Frequency Range: 37Hz - 24khz
Max Peak SPL: 112 dB SPL C-Weighted
Max Peak Input: +23 dBu
LF DRIVER SIZE: 203 mm (8")
HF DRIVER SIZE: 25 mm (1")
LF DRIVER POWER AMP: 56 W Class D
HF DRIVER POWER AMP: 56 W Class D
LF Trim Control: +2 dB, 0, -2 dB
HF TRIM CONTROL: +2 dB, 0, -2 dB
Input Types: 1 x XLR, 1 x TRS Balanced
AC INPUT VOLTAGE: 100-240 VAC +/- 10% 50/60 Hz
Dimensions (H x W x D): 419 mm x 254 mm x 308 mm
Weight 8.6 kg

Main features:
Image Control Waveguide
JBL Transducers are legendary for their performance
JBL’s Patented Slip Stream™ low frequency port design
Big Power, Big Sound
Professional Balanced Inputs
Selectable Input Sensitivity
LF Trim and HF Trim “TRIM” switches
JBL Professional Reliability
JBL LSR Design - Your Music Needs a Point of Reference
Deep Pedigree
