Learn complex part modeling in solidworks
This video will show complex part modeling in solidworks.
The WW2 grenade has some complex geometry. This video shows you hybrid modeling techniques in solidworks that can be applied to create complex part geometry.
Hybrid modeling in solidworks uses a combination of solid and surfacing modeling tecnhiques to model a complex part.
🔔 Subscribe and hit the bell to get notified about our weekly videos
/ designmountain
Timestamps:
0:00 complex part modeling solidworks intro
0:54 main body revolve
2:40 body cut – revolve cut
4:20 sweep for body cut
4:45 circular pattern
4:54 combine / subtract
6:12 head geometry
8:50 grip detail
11:20 pin loop
12:15 pin
14:26 outro
