Tata LPO 1618 5L Bus Chassis Specification Highlights
Check all the Tata LPO 1618 5L bus specifications here on TrucksBuses The main driveline of this Tata bus chassis includes a 4 cylinder NG 5L Turbotronn engine that produces a maximum power of 177 HP and a torque of 590 Nm Gearbox matched with this engine is 6 speed (6F+1R)Tata LPO 1618 5L bus comes with a gross vehicle weight of 16200 kg and offers length of 10815 mm (5700 wb), 11865 m (6200 wb) For the comfortable journeys, weveller, parabolic (optional), air (optional) in front and weveller, parabolic (optional), air (optional) in rear does the duty in this Tata bus chassis Other Tata LPO 1618 5L bus specifications like chassis, width, tyre, turning circle dia are available here in the tables on this page.

Tata LPO 1618 5L bus GVW is 16200 Kg

Tata LPO 1618 5L bus comes with a 6 speed (6F+1R) transmission

The tyre size of Tata LPO 1618 5L bus is 295/80 R22.5# Tubeless radial

In terms of performance, Tata LPO 1618 5L bus chassis produces a maximum power of 177 HP@2300 rpm and a maximum torque of 590 Nm@1000-2000 rpm

Tata LPO 1618 5L bus comes with Diesel fuel option and its fuel tank capacity is 250 Litres (5700 wb)# 350 Litres (6200 wb)

Engine NG 5L Turbotronn
Fuel Injection System Common Rail
Engine Displacement 5005 cc
Engine Cylinders 4
Engine Location Front
Power 177 HP@2300 rpm
Torque 590 Nm@1000-2000 rpm
Clutch 352 mm dia Transmission 6 speed (6F+1R)
Gearbox G750 OD
Max Speed 80 Kmph
Emission Norms Compliance BS6
Fuel Type Diesel
Fuel Tank Capacity 250 Litres (5700 wb)
350 Litres (6200 wb)
Electricals Battery 2x12 Volts, 150 Ah
Alternator: 80 Amps

GVW 16200 Kg
Overall Length 10815 mm (5700 wb)
11865 m (6200 wb)
Overall Width 2585 mm
Vehicle Configuration Chassis without face-cowl
Chassis Frame Ladder type
Axle Configuration 4x2
Rear Axle Single speed hypoid
Fully floating
Front Suspension Weveller
Parabolic (Optional)
Air (Optional)
Rear Suspension Weveller
Parabolic (Optional)
Air (Optional)
Tyres 295/80 R22.5
Tubeless radial
Wheelbase 5700 mm
6200 mm
Turning Circle Diameter 19.4 m (5700 wb)
21.1 m (6200 wb)
Front Overhang 1845 mm (5700 wb)
2265 mm (6200 wb)
Rear Overhang 3270 mm (5700 wb)
3400 mm (6200 wb)
