Billiard Cue Tip Lathe - Complete Assembly Guide

Billiard Cue Tip Lathe - Complete Assembly Guide | Shaft & Tip Holder Modules

Find the items here:
https://ko-fi.com/nightcafebilliard

After two months in the field, here's the official assembly guide for the billiard cue tip lathe! This step-by-step tutorial covers everything you need to know to properly assemble both the shaft holder and tip holder modules.
🔧 What You'll Learn:

Shaft Holder Module Assembly
• Installing ball bearings with circlips (correct orientation)
• Pressing and centering the cue holder
• XY-contour compensation tips (0-0.15mm)
• Rubber coupling installation for quieter operation
• Proper shaft clamping technique
Tip Holder Module Assembly
• Bearing and circlip installation
• Shaft tip screw pressing technique
• M3 nut insertion and screw threading
• ⚠️ CRITICAL: Sanding screws to prevent shaft damage
• Rubber element installation with proper fin alignment
• Leather tip holder assembly

⚠️ Important Safety Note:
Don't skip the screw sanding step! Rolled-thread screws can damage rubber adapters and scratch your shaft if not properly smoothed.
🔗 Resources & Community:
💬 Discord Community:   / discord
📦 3D Print Files: https://ko-fi.com/nightcafebilliard
🎯 Patreon Support: Early access + exclusive training docs:   / nightcafebilliard
Questions? Suggestions? Drop them in the comments or join our Discord community!
