Exploring the Tesla Coil Driver Board, Full Review & Test Results

This project is sponsored by PCBWAY https://www.pcbway.com/?from=MirkoP
Only $29 for an SMT prototype order. Free shipping & free stencil.
This is a relatively cheap complete Tesla coil driver, so we only need a primary and secondary coil, and in a few minutes we can make a good, powerful, functional Tesla coil, suitable for long-term continuous operation.
SAFETY NOTE: Please do not attempt to recreate the experiments shown on this video unless you are familiar with High Voltage Safety Techniques! Direct Current even above 60V maybe lethal, even when the AC supply voltage has been disconnected due to the stored energy in the capacitors.

Detailed instructions and tests at: https://www.hackster.io/mircemk/explo...

Chapters:
0:06 Short Demo
1:34 Description
6:33 In real conditions
8:05 Demonstration
9:36 Music Tesla Coil
10:18 Thermal Analysis
11:40 Conclusion
