جهاز اختبار مراقبة💪 Tester AHD / TVI / CVI / التناظرية 1080P / 3MP / 4MP / 5MP ، DC12V VGA😮🤫

5 بوصة 4 في 1 CCTV Screen Tester ، AHD / TVI / CVI / CVIBS جهاز اختبار مراقبة الفيديو المحوري التناظري ، جهاز اختبار كابل UTP / PTZ لكاميرا الأمن التناظرية 1080P / 3MP / 4MP / 5MP ، DC12V VGA Output Camera Tester محمول مراقبة الفيديو






Description
Tips
●To avoid the battery can't charge next time. Don't recharge it until the battery was completely used
●This tester NOT supports IP Camera
Product Functions
PTZ controller
Video signal testing
DC12V 1A output power
Image generator: Multi-format video OUT port image generator, sending a variety of standard (e.g. PAL, NTSC) color graphics section
Audio testing: Test the audio input from pickup devices. Connect the tester and pickup device with the audio cable.
Enhanced network cable testing: By UTP CABLE TEST port on the meter, you can test the connection of network cable.
VGA/HDMI input: Support VGA/HDMI 1.1 Compliant Digital input, once connect VGA/HDMI video, please switch selector to select HDMI or VGA mode.
TVI camera test: HD TVI video surveillance testing, support 1MP, 2MP, 3MP, 4MP, 5MP. When TVI signal input, the tester will display HD TVI camera image.
AHD camera test: HD video surveillance testing, support 1MP, 2MP, 3MP, 4MP, 5MP. When AHD signal input, the tester will display the AHD camera image.
CVI camera test: HD video surveillance testing, support 1MP, 2MP, 3MP, 4MP. When CVI signal input, the tester will display the CVI camera image.
LED lamp: It is useful for the engineer to install and maintain security system at night; LED On/Off pressing button, easy to operate.

Feature
Language settings: English, Chinese, Korean, Russian, Italian, French, Polish, Spanish, Japanese etc
Auto power off: 1-30 (mins)
Working Temperature: -10℃---+50℃
Humidity: 30%-90% Rh
Dimension: 221mm x 175mm x 91mm
Weight: 0.75kg

Packing list
1X HD coaxial tester
1X Adapter DC5V 1.5A（with USB cable)
1X International Standard 18650 2600ma battery
1X BNC cable
1X RS485 connector
1X Power output conversion cable
1X Audio cable
1X Lanyard
1X Tool bag
1X Instruction Manual

Features
5.0 inches 800 x480 High-resolution view angle display, more intuitive and easy to display the camera image quality, support PAL/NTSC standard video signal。Support CVBS + AHD (5MP) + TVI (5MP) + CVI (4MP) Camera Test，4-In-1 CCTV Tester Monitor
Developed for the on-site installation and maintenance of Analog Camera (CVBS) and HD Coaxial Camera, having TVI,CVI, AHD. (NOT Support IP Camera). It also provides many useful functions, such as video display, PTZ control, DC12V output power, audio test, image generator, VGA video signal input, HDMI1.0 signal input, RS485 data searching, cable testing, LED lamp etc.
Video monitor tester, High-resolution 5.0 inches 800 (RGB) x480 wide viewing angle display, Viewing angle larger, more intuitive and easy to display the camera image quality. Support PAL/NTSC standard video signal.
PTZ controller: Video monitor tester built-in Pelco-D / P PTZ control protocol,etc. , through its own RS485 interface, the user can control the PTZ up, down, left, right rotation, and adjust one machine zoom, focus,aperture size.
DC12V 1A output power: Power the camera with DC12V (1A) power output from the tester. It is helpful for demo and testing when the power supply is not available. Rechargeable: Built-in 18650 2600mA battery X 2,after charging 3-4 hour, working time lasts 11 hours.
