How to repair Volkswagen Touareg and Porsche Cayenne instrument clusters with dim or blank display

👨‍🔧 This video shows how to fix the instrument panels of Porsche Cayenne Mk1 (955 / 957) and VW Touareg Mk1 (7L) with not working middle LCD screen (the display could be very dark or dim, or even get completely blank). This backlighting issue of the colour display of Porsche Cayenne and Volkswagen Touareg dashboard is caused by some faulty components on the main board, in detail: 1 transformer, 2 inductors and 3 transistors. This tutorial shows how to replace those components and fix the LCD lighting problem.

🔧 Tools and spare parts useful for this repair:
• Transformer for Volkswagen Touareg 7L and Porsche Cayenne 9PA speedometers SEITRA03 https://store.minitools.com/en/seitra...
• 221k Inductor SEI-IND221K https://store.minitools.com/en/sei-in...
• 101k inductor SEI-IND101K https://store.minitools.com/en/sei-in...
• BPC56 NPN Transistor SEI-BCP56 https://store.minitools.com/en/bcp56-...
• BSP171 NPN Transistor SEI-BSP171 https://store.minitools.com/en/bsp171...
• Minitools pry tool SEP-LEV01C https://store.minitools.com/en/trim-r...
• Minitools gauge face large protective disc SEP-PRO01A https://store.minitools.com/en/sep-pr...
• Minitools gauge face small protective disc SEP-PRO01B https://store.minitools.com/en/sep-pr...
• Minitools flush cutter with slim tip SEP-TR01M https://store.minitools.com/en/sep-tr...
• Minitools shim for fitting instrument clusters needles SEP-INS03 https://store.minitools.com/en/sep-in...
• Soldering station with accessories SEP-KITM02A https://store.minitools.com/en/939d-s...
• Tweezers with rounded tips SEI-MTQ-13 https://store.minitools.com/en/sei-mt...
• Solder wick SEI-TRE2B https://store.minitools.com/en/sei-tr...
• Solder extraction desoldering iron;
• Torx T10 screwdriver.

📌 For more information on spare parts useful for repairing instrument clusters, infotainment systems, car radios and sat-nav, visit https://store.minitools.com

0:00 Intro
0:27 How to disassemble Volkswagen Touareg and Porsche Cayenne instrument clusters
1:39 How to de-solder all faulty components from Porsche Cayenne and VW Touareg dashboards PCB
3:58 How to solder the new components on the PCB to fix VW Touareg and Porsche Cayenne LCD screen
5:51 How to re-assemble the instrument panels of Porsche Cayenne and Volkswagen Touareg
6:44 How to switch on VW Touareg and Porsche Cayenne speedometers on a test bench
