410- Ansys Maxwell | Core loss 3 phase Transformer [1/3]
Автор: kamyar K
Загружено: 2016-01-10
Просмотров: 59766
Описание:
Ton of points and tricks are described in this video.
Transient simulator is used to calculate the core loss of a 3phase transformer. for accurate simulations a measured material properties for core loss and BH curve has been used that has been used by Ansys for a REAL client and REAL transformer design.
Advanced material definition is covered in this video.
Please find the necessary files from link below.
http://www.ece.ubc.ca/~keikhosr/Bargo...
