Disassembling just about anything is simple, it’s getting it back together afterwards that is the hard part! Either way, our tech goes over disassembling, and then covers the reassembly of the vent wing windows for our 1971 Super Beetle Project. This was a little more difficult as we painted our frames black but the same processes will apply for stock, chrome plated and polished assemblies. It will just be easier since there is less worry about scratching paint!

Intro 0:00
Vent wing disassembly: 1:13
Glass and inner frame removal: 1:39
Latch catch removal: 2:43
Latch removal: 2:55
Vent wing reassembly : 3:53
Latch installation: 4:02
Glass to frame installation: 4:33
Vent wing seals installation: 5:28
Latch plate installation: 6:40
Glass and inner frame installation: 7:05

-------------------------------------------------------------

Disassembly tools used in this video:
3/8” Drive Ratchet
3/8” Drive 10mm Driver
Small Flat Blade Screw Driver
Large Flat Blade Screw Driver
Pocket Knife
Rubber Mallet
Small Punch
Drill
1/8” Drill Bit
1/4” Drill Bit
Side Cutters
Pliers

Assembly tools used in this video:
Large Wood Vice
Vice Grips
Brass Hammer
Pop Rivet Tool
Trim Tool
1/4” Drive Ratchet
1/4” Drive 10mm Driver
Needle Nose Pliers
Various Punches and Chisels
Large Flat Blade Screw Driver
Razor Blade
1/8” Drill Bit
3/16” Drill Bit

Chemicals Used:
Weather-strip Adhesive

-------------------------------------------------------------

Parts used in this video:

VW Vent Wing Glass to Frame Seal (241-295A)
https://www.jbugs.com/product/241-295...

VW Left Vent Wing Lock (111837657A)
https://www.jbugs.com/product/1118376...

VW Right Vent Wing Lock (111837658A)
https://www.jbugs.com/product/1118376...

VW Vent Wing Lock Rivets (111-647A)
https://www.jbugs.com/product/111-647...

VW Left Vent Wing Window Seal (111837625B)
https://www.jbugs.com/product/1118376...

VW Right Vent Wing Window Seal (111837626B)
https://www.jbugs.com/product/1118376...

VW Left & Right Vent wing Flap Seals (241837465)
https://www.jbugs.com/product/2418374...

VW Vent Wing Pivot Rivets (111-648)
https://www.jbugs.com/product/111-648...
