Siemens S7-1200 XOR, ENCODE, DECODE, OR

In this video we start programming the Siemens S7-1200 in SCL to place pallets in the Stacker Crane Rack.

The programming has been developed in such a way to allow easier coding for the removal of pallets from the rack, which we will implement in Video 16.

We make use of the XOR, ENCODE, DECODE and OR commands and explain each of them using an animation.

Links for previous videos in the series you may like to watch are below.

Purchase Factory I/O
If you would like to purchase FactoryI/O, you can use the link below. I will earn a small commission for this, however, it helps me produce videos like this one to help you program PLCs now and in the future and it shouldn't make a difference to the price you pay. Many thanks.
https://factoryio.com/url-action?ref=...

Details about my patreon account will be added here shortly.
