PRS Partial Coil Split
Автор: Six String Supplies
Загружено: 2022-05-22
Просмотров: 15019
In part 2 - we add a master coil split using a push pull pot for the tone control.
The circuit is identical to our standard setup in part 1: • How To Wire: 1 Volume, 1 Tone, 3 Way Toggl...
You need to watch this before attempting part 2.
Our tone control now acts as a master coil split for each humbucker. As it is based on the PRS model, we have added 2 resistors to the push pull pot to create a partial split - ie. not all of the signal is sent to ground during a coil split. Partial coil splits nicely balance out humbuckers if you find them sounding too weedy and thin when split.
PRS Wiring Kit: https://sixstringsupplies.co.uk/produ...
Guitar Wiring Diagrams: https://sixstringsupplies.co.uk/pages...
All components are available from our website: https://sixstringsupplies.co.uk/
