Humbucker Push Pull Pot Series Parallel Wiring
Автор: Six String Supplies
Загружено: 2020-01-31
Просмотров: 44678
In this video we demonstrate how to wire a humbucker into a push pull pot to enable series/parallel switching.
Using a very simple rig consisting of a volume control and a jack socket, this video shows how to wire a 4 conductor Seymour Duncan into a CTS push pull pot.
The vast majority of humbuckers are wired in "series". In this setup, activating the push pull pot enables "parallel" wiring. This creates a brighter tone from the pickup but results in a considerable loss in output.
For quality guitar electronics, visit our website: https://sixstringsupplies.co.uk
More guitar wiring tutorials: • How to Wire an ES 335 - Wiring an ES-335 H...
Mini tutorials: • Soldering Braided Guitar Wire to Pots
Guitar Wiring Diagrams: https://sixstringsupplies.co.uk/pages...
#guitarwiring #guitarwiringmods
