Yamaha YFZ450 Build - Part 3 - Tear Down - Engine Motor Bottom End, Oil Tank Radiator, Steering Stem

Yamaha YFZ450 Build - Part 3 - Tear Down (Disassembly) - In this video we will continue tearing down the the 4 wheeler to get the frame, subframe (sub frame), swingarm, and a-arms ready for powder coating (powdercoating) and the engine (motor) ready for vapor blasting & rebuild. We will also be removing the motor from the frame by unhooking and removing the stator (alternator), wire harness clips (wiring harness clips), flywheel bolt, starter reduction gear, timing chain guides, timing chain, piston, wrist pin, counter balancer bolt & bracket (counterbalancer), crankshaft bolt & gears, clutch cover (right crankcase cover), clutch basket, clutch inner, pressure plate, clutch fibers (clutch discs), clutch springs, shift shaft, shift drum stopper arm, oil tank, radiator, temperature sensors, steering stem, tie rod ends, pivot bolt, and motor mounts. We unhooked and removed all of the nuts, bolts, thrust washers, collars, bushings, adjusters, springs, seals, crush washers, circlips, snap rings, clamps, brackets, and rubber grommets. This is an atv build quad 4-wheeler rebuild. Yamaha YFZ450 YFZ450r Restoration, Restore.

0:00 - Short Build Intro - New Parts
2:09 - Flywheel Removal
5:43 - Timing Chain & Guide (Cam Chain)
7:45 - Spun Crank Bearings (Junk Crankshaft Bearings)
8:59 - Piston & Wrist Pin
12:04 - Clutch Cover (Right Crankcase Cover)
13:40 - Counter Balancer Bolt (Counterbalancer)
17:10 - Crankshaft Bolt & Gears
18:16 - Clutch, Pressure Plate, Clutch Basket
21:50 - Remove Drive Gears & Counter Balancer
23:44 - Transmission, Shift Shaft & Oil Pump
31:28 - Oil Tank
32:36 - Radiator & Temperature Sensors
29:28 - Camshafts & Cam Caps (Covers, Holders)
35:10 - Steering Stem & Tie Rod Ends
40:26 - Pivot Bolt & Motor Mounts
49:30 - Lift Engine Off Frame (Remove Motor)
50:20 - Outro, Recap, Future Episodes
