GRID DIP METER GDO Part2; DIGI-DIP Full Details on my Digital Dipmeter Design.

Today's Video is the 2nd Part of the Series that is all about the fairly forgotten and nowadays probably obsolete piece of equipment, that exists since the 1920's and was a important Piece of Equipment for HAM Operators and TV, Radio repair-shops back in the day.

In this Part I give you full Details on the Design of my DIGI-DIP MCU Controlled (and way over-engineered :-) Digital Display DIP Meter.

I started the Design in early 2019 as a fun Project, but because of Private reasons and because I got distracted (as so often) with other more interesting to me Designs, I abandoned and it's got frozen in Time as a working Prototype:-) I do not plan to continue Developing it, though the Hardware and Software is in a working state but needs refinement.

Therefore, if anybody is truly interested in continuing the Project in means of Hard and Software from the current state on, I am willing (on request in the comments) to provide ALL the Eagle files and Software as well any other necessary Design files for the Base Unit and all the Oscillator Versions I made.

GRID DIP METER (GDO) Part1; History + LEADER LDM-815 Teardown and Tests:    • GRID DIP METER (GDO) Part1; History + LEAD...


Further on request, Software and necessary design files (for the Build) are available if somebody wants to build the current working Version.
