Stop Section with Märklin START UP Light Signals 74391/74380/74371 using M84 60842/60841 (Beg Ep 5h)

In this video we look at how to make a stop section (or stop track) with the Märklin START UP Light Signals using the M84. A stop section is a section of track where the power is turned off when the signal is red such the locomotive/train will stop. The section is powered again when the signal turns green.

The stop section can be used with both the Märklin START UP Home Block Light Signal (Märklin 74391) and the Yard Light Signal (Märklin 74371). The Märklin START UP Distant Signal (Märklin 74380) may also be used in connection with the Home Block Light Signal. You can use the black edition M84 (Märklin 60842) or the white edition M84 (Märklin 60841) to create the stop section.

When creating a stop section (or stop track) the stop section is completely powered off stopping the locomotive/train. This means you need to test with all your locomotives on your layout to ensure they stop the correct place. Disadvantage is no power means light and sound also turns off.

In this video we use the same set up as in Beginner Episode 5g.

More Information / background videos
Installing Märklin START UP Light Signals 74391/74380/74371 using M84 60842/60841 (Beginner Episode 5g):    • Install Märklin START UP Light Signals 743...

ALWAYS do the installation with POWER OFF and read the manual.

Tips & How to included:
• How to install stop track with START UP signal and m84
• How to wire the stop track
• Tip: The stop section must be long enough for the train to stop
• Tip: Test with all your trains - they will roll different lengths

Enjoy and have fun with model trains :-)

Interesting links (English):
Märklin: https://www.maerklin.de/en
Märklin START UP Signals:
Märklin 74391: https://www.maerklin.de/en/products/d...
Märklin 74380: https://www.maerklin.de/en/products/d...
Märklin 74371: https://www.maerklin.de/en/products/d...
Märklin M84s:
Märklin 60842: https://www.maerklin.de/en/products/d...
Märklin 60841: https://www.maerklin.de/en/products/d...

Chapters
00:00 Intro
02:37 What is a stop section (or stop track)
03:33 Installing stop section insulators
08:12 Optional bypass wire
10:19 Power to stop section
11:46 Track power to m84 center
14:46 Wire summary
17:33 Demo with locomotive
18:30 Stop section considerations
21:11 Summary & Tips
