12V-2A SMPS Repairing using 5L0380R||Make a PWM Circuit for SMPS

12V-2A SMPS Repairing using 5L0380R||Make a PWM Circuit for SMPS
Stone Mind Techno
about this video-
es video mein mere dawara dikhaya gya hai ki 5L0380R se kis Parkar pwm circuit ko banaya ja sakta hai agar kisi bhi SMPS ka pwm ic damage Ho Gaya hai same number nahi Mil raha hai switching MOSFET damage Ho Gaya to es ic Ko SMPS me laga kar SMPS Ko repair kiya ja sakta hai ye ic 5L0380R normally market mein Mil jayega or 75 Watt tak ke SMPS power supply circuit board Ko repair kiya ja sakta hai esko kisi bhi SMPS me laga sakte hai eske liye kuch components ko alag se add kar circuit Ko complete Kiya Jata hai jesa ki agar kisi SMPS me optocuplor nahi laga hai to Alag se feedback ke liye add kar sakte hai jese vcc ke liye 220K resistor,pc817,220 ohm resistor 104 capacitor,100uf50 capacitor,10k variable resistor ko video mein dikhaye gye tarike se add kar circuit complete kar lena hai or SMPS me lagaye aapka SMPS properly work karega mere dawara circuit complete kar SMPS Ko check kar dikhaya gya hai ye sahi se kaam kar Raha hai ye jankari aapko kesi lagi comment karen thanks for following me and my youtube channel Stone Mind Techno.

This video related circuit diagram link -https://drive.google.com/file/d/1FVSs...

My other related video link-   • 5L0380R Circuit Diagram||SMPS PWM Circuit ...

#12V 2A SMPS Repairing video
#how to repair damage power ic SMPS
#how to install 5L0380R power supply circuit
#STR 5l0380R Ko SMPS me kese lagate Hain
#5l0380r circuit diagram
#Stone Mind Techno
#smpsrepair
#smpspowersupply
#how to use STR 5l0380R any SMPS
#12V 2A SMPS checking hindi video
