DIY: Midi TRS Type-A cable for KORG devices

I bought a random TRS cable from Amazon and made it into a Midi TRS Type-A cable for use with Korg devices. If you want to convert a Midi TRS Type B to Type A please watch here 2:00 if you have any questions just ask it in the comments, I'd be happy to help!

Most Midi TRS type cables are of Type B if you want to make a Type A make sure the Midi pins readout as follows... 0:30
TRS Type A Midi pin readouts:
4 = Ring
2 = Sleeve
5 = Tip

Always check the pin readouts before soldering using a voltmeter!!!!!

You need a TRS Type-A to use the Korg NTS-1 on a midi keyboard.

Instagram:
  / _decima1

Twitter:
  / _decima1

Help support the channel ETH donation here:
0x34577Ff1b8386f9E488BC46233cab5B8911DE909

From the KORG website about the NTS-1:

Build it, tweak it, connect it; a world of synthesis at your fingertips!
Korg is always creating new ways to experience hands-on, fun music-making.
Now, you can too.

The Nu:Tekt NTS-1 digital KIT is a unique, flexible, and easy DIY synthesizer that you can easily assemble yourself (tool included), without any soldering.

The first of its kind from KORG’s DIY-focused Nu:Tekt brand, NTS-1 packs a powerful synth and multi-effects engine into a compact and highly portable form factor. Its DIY nature means it’s also very customizable. Explore the possibilities!

NTS-1 is also completely compatible with the logue-SDK*, making it possible to create custom oscillators and effects or upload any of the content available for minilogue xd and prologue.

Belying its size, the Nu:Tekt NTS-1 features a digital oscillator inspired by the MULTI engine as found on the acclaimed prologue and minilogue xd, along with an extremely capable arpeggiator including multiple ranges, scales, and modes, plus dedicated spatial, modulation, and delay sections, each with multiple settings to explore.

With a single monophonic digital oscillator, one multimode filter, on EG, three LFOs, three stereo effect processors, and full arpeggiator, the NTS-1 is a very powerful, flexible, fun-to-explore synth.

The main oscillator can produce Sawtooth, Triangle, Square and VPM waveforms, and can load custom oscillators created from Korg’s logue SDK, which means it’s compatible with content created for prologue and minilogue xd. These waveforms can be easily re-shaped and adjusted just by simply turning a couple of knobs.

A wide selection of filters (Low pass 2/4-pole, High pass 2/4-pole, Band pass 2/4-pole and OPEN mode, all with resonance) give you serious control over the overall tone of the oscillator.

The three onboard effects units are inspired by those on KORG’s minilogue xd, which itself took onboard effects to a whole new level. Numerous reverbs, modulation effects, and delays are available to blend and edit at will, to really finish out your sound creations.

NTS-1 also offers a fun and practical arpeggiator with several patterns available. Scales and numerous note orders including a Random mode are also available to create new and original ideas on the fly. The pattern length can be adjusted (from 1 to 24 steps) and, when synced externally, the step duration can also be adjusted (16th to 64th notes)

Thanks to its ribbon controller, simple interface and display, the NTS-1 can be played and enjoyed very intuitively. Deeper parameter changes are also possible with several combinations of buttons / knobs, furthering the possibilities. Don’t let its size fool you; NTS-1 goes deep but keeps it all easily accessible.

Customize the experience
The fun isn’t over after you finish building the NTS-1. The screws on the side panels are long enough to let you easily attach custom side panels.

Get creative and use the NTS-1 in a wide variety of setups. Equipped with AUDIO IN, SYNC IN, SYNC OUT and MIDI IN connectors, the NTS-1 can easily be used in combination with other hardware and software.
