KTS - Wire Mesh in Tekla Structures
Автор: Keyack Technology Solutions
Загружено: 2025-01-24
Просмотров: 1960
This video shows how to model in wire mesh often used in miscellaneous steel detailing for guardrails or safety barriers in fencing. You will see how to create the mesh with beam parts, then fuse them together with the Part Add command, creating a standard Shape Item Geometry in Tekla, and then even using the array command to create a parametric custom component part to allow the user to adapt the lengths of the mesh to whatever they need.
Chapters
00:00 - Introduction
00:39 - Wire Mesh Rolls
01:44 - Model Bars Using Beam Command
05:04 - Part Add to Fuse Bars into One Mesh
07:57 - Create Shape Item Geometry
16:08 - Copy Shape to FIRM Folder
17:46 - Custom Component vs. API Plugin
20:32 - Intelligence Behind Parametric Custom Component
