Increase FPV Drone Range with DIY 5 Turn Helical Antenna and Li-ion Battery. VTC5a 18650

In this video I'm testing out two DIY projects which should significantly improve range. The first is a 5 Turn Helical Antenna for video signal, and the second is a 2500mAh Li-Ion Battery Pack. These are both a must-have for anyone looking to improve range! The best part is that they are both pretty cheap and easy to make with basic tools and knowledge.

18650 Li-Ion Battery Notes:
The Sony VTC5a Li-Ion battery is actually 2600mAh, but I call it 2500mAh because this is the real capacity that you should expect. Using all 2600mah would basically kill the battery.
The Max Amps for the Sony VTC5a is 35A, however this "max" for very short bursts, continuous flying you should not exceed 25A. I'm usually around 15A, but the max Amps for this flight was 32A.

Links to DIY projects:
DIY 2500mAh Li-ion Battery Video:    • DIY Long-Range FPV Battery, using Li-Ion b...
DIY 5 Turn Helical: Not completed yet, but let me know in the comments if you'd like to see this.

5" Drone Setup Details (Started using 6" props actually as I do a bit of long-range)
Flight Controller: Matek F405-CTR
VTX: Matek Mini 800mw
GPS Module: iFlight GPS Modul
Motors: XING-E 2306 2450KV
ESC: Aikon AK32 35A 2-4S BlHeli32
Propellers: HQ Ethix S5 5x4x3
FPV Camera: Some old Eachine; need to upgrade this...
Radio Receiver: TBS Crossfire Nano RX
Receiver Antenna: TBS Crossfire Immortal T V2 Antenna
VTX Antenna: SpiroNET Omni – 5.8GHz CP Antenna

Googles/Antennas
Fatshark HDO with Rapidfire Receiver
Foxeer Micro Lollipop 3 CP
SpiroNET 5.8GHz 13dB Patch

Controller/Transmitter
FRSKY Taranis X9D Plus with TBS Crossfire Micro TX V2

Cameras, Footage, and Software
GoPro Hero 8 Black, shot in 2.7k
Various iPhones
Final Cut Pro X (FCPX) editing software

If you have any questions or comments about my setup please leave a comment.

Note: All equipment and flight plans were in accordance with current local laws. Special thanks to my spotters who hiked hard terrain with me in order to achieve this flight footage.
