Balanced Y Configurations (Full Lecture)

In this lesson we'll discuss general 3 phase AC circuit analysis strategies and take a detailed look at balanced 4 and 3 wire Y configured loads in 3 phase AC systems. We'll examine voltage distribution and current flow through balanced Y configured loads and learn that voltage and current magnitude, relative phase shift, apparent, real, and reactive power are identical for each branch impedance comprising the balanced Y configured load. Additionally, we'll learn a balanced configuration carries no current in the 4th neutral wire. Finally we'll learn a balanced 3 wire Y configured load can be effectively treated as a balanced 4 wire Y configuration simply lacking the 4th wire. (Full Lecture)

MINOR ERROR @ 39:30 - Total apparent power should have an angle of 20 (not 28) 432VA at 20 correctly resolves into 405.9W and 147.8VAR

___________________

If you wish to support this project please visit the Patreon page at:   / bigbadtech

___________________

Copyright information: Use this lecture. Use it at home, at work, or at school. Put it in a playlist, embed it in a website, share it with your coworkers, family, friends, and enemies. I made this lecture and posted it on YouTube so users everywhere have free access to this information.

This being said, this YouTube channel is meant to be the sole point of distribution for this lecture. Users are not authorized to download it, change it, or charge for access. Don’t even think of downloading it and uploading to your own channel and pretending it’s your own work. Not cool. Use this lecture and let your friends know this free resource exists.

Use it. Don't steal it. Be cool.
