Build a Motor Control Trainer Board, Plug, and Motor Mount

In this guided application exercise we'll build a bare trainer board, assemble a plug, and motor mount. From these base states we will build many motor control projects.

For those interested in replicating this application exercise here's the parts list from Automation Direct:
72120NP (PLUG 20A 120/250VAC 4-POLE 5-WIRE NEMA L21-20 LOCK BLK/WHT NYLON), BLD (PLUGBOX LOCKOUT 20A & 30A LOCKING PLUGS & CONN RED PLASTIC), FG2 (COVER UNFUSED ALL 75VA & 100VA MLI & MGJ 50VA PRIMARY OR SECONDARY SIDE), FGF2 (COVER FUSED ALL 75VA & 100VA & MLI/ MGJ 50VA PRIMARY OR SECONDARY SIDE), PH100MGJ (TRANSFORMER CONTROL 100VA 380x277x208VAC TO 240x120VAC), SA110-40SL (PB ENC 22mm 4-HOLE GRY 74mm DEEP PLASTIC)
