Transforming Data into Dialogue with Oasys
Автор: Oasys LS-DYNA Environment
Загружено: 2025-07-31
Просмотров: 208
Capturing accurate simulation data is just the first step in getting the right message across. Data analysis and tailored results presentation are equally vital in ensuring the right messages reach different target audiences. Join us in this webinar to discover the comprehensive set of tools in the Oasys Suite, catered to helping users perform in-depth analysis, alongside creating compelling and streamlined reports.
Key highlights:
-How to make the most out of Oasys D3PLOT Properties to enhance result presentation
-Deep dive into creating and saving annotations for live presentations
-How to share annotations efficiently through the use of GLB files
2:05 Introduction to Workflows
3:04 Intrusion Contour Plot Workflow Live Demo
8:52 Using Properties to Improve Result Presentation
12:45 Saving Property Files
14:10 Introduction to Annotations
15:51 Creating Annotations in D3PLOT
18:30 Reading envelope.h5 file to Obtain Enveloped Results
21:35 Reading and saving Annotation (.ann) files
22:45 Introduction to .glb Files and Demonstration of D3PLOT Viewer
25:30 Introduction to Report Viewer
Link to D3PLOT Viewer: https://d3plotviewer.com/
